Snapbloc Power Distribution Block - LDB-22-350

by ILSCO

Item# LDB-22-350 - Splicer Block, 1-P, 620A, Box/Box, Line & Load: (2)350MCM-6AWG, Touchsasfe

LDB Series Information

• Multiple Conductor Capability
• Unique Locking Feature
• Visual Inspection
• Easy to Assemble
• Modular Design
• UL Recognized
• CSA Certified
• 90 Degree C

Specifications

• Item Number: LDB-22-350
• UPC: 0783669595154
• Brand: Ilsco
• Item Category:Power Distribution Blocks
• Subcategory: Distribution Block
• Series: LDB
• No. of Poles: 1
• Amps (AC): 620 Amps
• No. of Inputs per Pole: 2
• No. of Outputs per Pole: 2
• Line/Load Connection: Box Lug
• Mounting Type: Panel Mount
• Input Wire Range: 350 kcmil~6 AWG
• Output Wire Range: 350 kcmil~6 AWG
• Includes Cover: Yes
• Voltage (AC): 600 Volts AC
• Composition: Polycarbonate
• Protection Level: IP20
• UL Compliance: UL1059
• Color: Black
• Approvals: UL;CSA
• RoHS: Yes
• H x W x D: 3 in x 3.57 in x 4.75 in

Please contact us for availability and pricing.
